Film Sealed NTC Thermistor Temperature Sensor For Printer

Gambar besar : Film Sealed NTC Thermistor Temperature Sensor For Printer

Detail produk:

Place of Origin:	CHINA
Nama merek:	HENG HAO
Sertifikasi:	UL CQC TUV ROHS
Model Number:	MF5E

Syarat-syarat pembayaran & pengiriman:

Minimum Order Quantity:	1000pcs
Delivery Time:	10 DAYS
Payment Terms:	T/T, Western Union
Supply Ability:	1000000PCS PER MONTH

Kontak

Film Sealed NTC Thermistor Temperature Sensor For Printer

Deskripsi

MATERIALS:

5. Sealed with insulating film

used for:

printer

Menyoroti:

Film Sealed NTC Thermistor Temperature Sensor

Printer NTC Thermistor Temperature Sensor

Film Sealed NTC Temp Sensor

FILM-SEALED NTC THERISTOR Temperature sensor for printer

FEATURES

Sealed with insulating film,quick thermal reaction, high sensitivity
Good stability, high reliability
Good insulation
High precision fo resistance value
Safe for use
Small volume, light weight and convenient for installing in narrow environment

PORPOSE

Temperature measurement

Temperature control

Temperature compensation

APPLICABLE SCOPE

Temperature, printer, household appliances

MAIN TECHNICAL SPECIFICATIONS

Specification Name	Scope	Detection Condition
R25(nominal resistance value)	10KΩ~100KΩ	Constant temperature 25℃±0.05℃
R25 Permissible variance(%)	±1,±2, ±3, ±5	Constant temperature 25℃±0.05℃
B25/50 (material coefficient)(thermal-sensitivity index)	3300~4200K	Constant temperature 25℃±0.05℃ Constant temperature 50℃±0.05℃
B25/50 Value permissible variance(%)	±1,±2	Constant temperature 25℃±0.05℃ Constant temperature 50℃±0.05℃
∫(dissipation coefficient)	≥0.7mw/℃	Static in the air
T(thermal time constant)	≤5S	Static in the air
Ta(Working temperature)	-30℃~+120℃
Pn (rated power)	≤25mw	within working temperature

Film Sealed NTC Thermistor Temperature Sensor For Printer 0
